Electric Forklifts

1.5 Ton Electric Forklift

  • ModelAX-EF15
  • Power systemElectric
  • Primary applicationWarehouse and Material Handling

A four-wheel AC electric forklift with a 1,500 kg rated capacity at a 500 mm load centre. The supplied specification lists a 3,000 mm standard mast and a maximum mast height up to 6,000 mm. Final selection depends on the load, aisle, mast, tyre and power-system requirements.

Rated capacity
1,500 kg
Load centre
500 mm
Standard mast
3,000 mm
Drive type
AC, 4-wheel
Get Price & Lead Time Check My Application

Share your working requirements, quantity and destination. We’ll review the application and confirm the right configuration before quoting.

1.5 Ton Electric Forklift

Buying checklist

Start With the Job, Not Just the Price

The right machine depends on the job, the site and the expected workload. Review the points below before comparing quotations.

Where This Model Fits

  • Loads within the rated configuration

    Use 1,500 kg at the stated 500 mm load centre as the initial selection reference. Confirm the actual load dimensions, lift height and any attachment against the final nameplate and load chart.

  • General warehouse transport and stacking

    The standard 3,000 mm mast provides a starting configuration for routine material handling where the required lift height, aisle, doorway and overhead clearances have been checked.

  • Sites that match the machine envelope

    The 1,100 mm overall width and 1,860 mm turning radius provide initial route-planning references. Confirm the working aisle and right-angle stacking requirement for the selected mast and load.

Confirm Before Ordering

  • Load weight, dimensions and load centre

    Rated capacity is tied to the stated load centre. Oversized, off-centre or irregular loads, higher lift positions and attachments may change the available capacity.

  • Lift height and overhead clearance

    Provide the highest placement point, doorway height and ceiling or container clearance. The final mast type, lowered height, free lift and capacity at height must be checked together.

  • Aisle, route and floor conditions

    Share the narrowest aisle and doorway, required turning space, floor condition and any ramps. These inputs affect route clearance, tyre selection and operating suitability.

  • Battery, charger and duty cycle

    The supplied specification identifies AC drive but does not state battery chemistry, voltage, capacity or charger input. Confirm daily hours, shifts, charging window and site power supply before quotation.

Configuration options

Available Options & Attachments

Availability, compatibility and any effect on rated performance will be confirmed for the selected configuration.

Fork length options

Fork length options

Available fork lengths: 1,070 mm, 1,220 mm, and 1,400 mm.

Tire Options

Tire Options

Solid and pneumatic tire options are available.

Color and Logo Customization

Color and Logo Customization

Custom color and logo options are available subject to order confirmation.

Send the working conditions you already know. We’ll help confirm the remaining configuration details.

Check My Configuration

Site planning reference

Plan the route around the machine envelope

Use the supplied dimensions below as initial planning references for the travel route and working area. Final clearance still depends on the selected mast, fork length, load position and site layout.

Overall width 1,100 mm

Compare with the narrowest doorway and travel path, allowing suitable operating clearance.

Overall length 3,260 mm

Use together with load length and fork choice when reviewing the working envelope.

Turning radius 1,860 mm

Use as an initial turning reference; confirm the required aisle with the intended load.

Overhead guard height 2,050 mm

Check doorway and overhead clearance together with the selected mast's lowered height.

Loaded performance reference

Review travel, lifting and ramp requirements together

These supplied values support initial comparison. The actual operating plan must also consider the load, floor, route, tyre choice, battery configuration and applicable operating instructions.

Travel speed, loaded
10 km/h
Lift speed, loaded
240 mm/s
Gradeability, loaded
14%

The listed gradeability is not an approved operating-slope instruction. Confirm the actual ramp, load, surface and operating procedure for the final configuration.

Full specifications

Technical Specifications

Use these figures for initial comparison. Final specifications may vary with the selected power system, attachments and configuration.

Item Specification
Model AX-E-Forklift-1.5T
Drive type AC, 4-wheel
Rated capacity 1,500 kg
Load centre 500 mm
Standard mast 3,000 mm
Maximum mast height Up to 6,000 mm
Fork length 1,070 / 1,220 / 1,400 mm
Overhead guard height 2,050 mm
Travel speed, loaded 10 km/h
Lift speed, loaded 240 mm/s
Gradeability, loaded 14%
Turning radius 1,860 mm
Overall width 1,100 mm
Overall length 3,260 mm
Tyre options Solid / pneumatic
Colour and logo Custom colour and logo available
Specifications are supplied reference values for the stated model. Final values, capacity and compatibility must be confirmed for the selected mast, forks, tyres, power system and other options.

Need a different capacity, working height, power system or attachment?

Ask About Options

Order assurance

Clear Records From Inspection to Shipment

Review the available inspection, compliance, packing and product records before placing the order. Confirmed documents will be listed in the quotation.

Pre-shipment Inspection

  1. TestTest
  2. TestTest

Certificates & Compliance Documents

TestTestTestTestTestTestTestTest
TestTestTestTestTest

Packing & Dispatch Records

TestTestTestTestTestTest

TestTestTestTestTest

TestTest

Buyer questions

1.5 Ton Electric Forklift FAQs

Find quick answers about capacity, configuration, site fit, operation and ordering. For a model-specific answer, include your application, target specification, quantity and destination.

Ask a Product Specialist
What is the rated capacity of this electric forklift?

The supplied rating is 1,500 kg at a 500 mm load centre. Actual available capacity must be checked against the final mast, lift height, load dimensions and any attachment using the applicable nameplate and load chart.

Which mast heights are available?

Which mast heights are available?

Which fork lengths can be selected?

The listed fork lengths are 1,070 mm, 1,220 mm and 1,400 mm. Share the pallet or load dimensions so the fork length and resulting load centre can be checked together.

Application review & quote

Tell Us About the Job. We’ll Recommend the Right AX-EF15 Setup.

Share the working target, site conditions, operating hours and destination. We’ll review the application and prepare a recommended configuration, price and estimated lead time.

  • Required capacity, working height, digging depth or other performance target
  • Working environment, available space, ground conditions and expected duty cycle
  • Preferred power source, attachment and other configuration requirements
  • Estimated quantity and destination country, city or port

The selected product and model are added automatically. Share only the details you know—our team will help confirm the rest.
